FPC50 filling, stoppering and capping system

FPC50 filling, stoppering and capping system

FPC50 is a highly flexible aseptic filling system with integrated, full or partial stoppering and crimp capping of vials. It provides a ready-to-use and easy-to-validate filling system for small batch production of vial sizes between 2R and 100H.

Designed for use under laminar air flow or in a restricted access barrier system, the FPC50 is available as a customised solution for integration into an isolator.

Providing fast and easy changeover between batches, the FPC50 handles up to 25 vials per minute and uses a minimum of space in a cleanroom. High filling accuracy prevents costly overfilling.

Filling is done by the integrated, highly accurate peristaltic dispenser, which can give an optimum filling accuracy for volumes from micro-volumes. This feature prevents costly overfilling of expensive liquids. As an option, the unit can do automatic gas purging before, during and after the liquid filling process.

A complete change-over between different liquids, vials or stoppers can be done by the operator within five minutes, without any technical support from outside the cleanroom.

FPC50 can be customised to fit different sizes of trays at the infeed and at the outfeed. The infeed tray can be positioned on the front of the FPC50 or on the left side of the unit.

Features and benefits

• Single-use fluid path ensures simple cleaning validation
• First-class documentation and test protocols for FAT, IQ and OQ
• Universal format parts for stoppers and crimp caps
• Ø13 mm and 20 mm stoppers and crimp caps
• Optional in-line check weighing and customised guarding
• Optional software to support FDA 21 CFR Part 11
• Batch report after each production run

Technical summary

Filling volume range	0.1-100 ml
Accuracy	±0.5 %
Capacity	1500 units/hour
闭锁装置	Ø13 mm and 20 mm
Cap diameter range	13-20 mm
Infeed and outfeed trays	Width/open end min. 200mm/7.9"-max. 305mm/12"

Technical Summary table lists features available within the range. See ‘Specifications’ tab for model specific information.
