Overview

FlatBioEndCap™ - End caps for connectors

FlatBioEndCap is produced from DMF listed polypropylene, compliant with FDA and USP Class VI and European Pharmacopoeia.

Features and benefits

Lot numbers moulded in for full traceability
年代uitable for sterilisation by autoclave and gamma irradiation

Technical summary

Max. operating pressure	4 bar
Max. operating pressure	58 psi
年代helf life	5 years
Certification	ADCF, ISO 14644-1 Class 7, ISO 9001, ISO10993, USP Class VI
TC Size	½-¾ TC - 2½ TC in

Technical Summary table lists features available within the range. See ‘Specifications’ tab for model specific information.

年代pecifications

Technical specifications

	FlatBioEndCap
Max. operating pressure	4 bar
Max. operating pressure	58 psi
Fluid temperature range	5 to 40 °C
Fluid temperature range	40 to 104 °F
Operating temperature range	-5 to 40 °C
Operating temperature range	23 to 104 °F
Autoclave stability	121 °C 30 minutes
Gamma stability	50 kGy
年代helf life	5 years
Certification	ADCF, ISO 14644-1 Class 7, ISO 9001, ISO10993, USP Class VI
TC Size	½-¾ TC - 2½ TC in
Quantity	10 PCS

Materials of construction

Material

Natural PP

Validation

About the BioPure components validation guides

These components are manufactured and packed in an ISO 14644-1 Class 7 cleanroom from a DMF listed polypropylene compliant with FDA and USP VI. Product validation studies were performed on the post gamma irradiated BioPure components.

Evaluated for extractables using a multi-solvent approach to BPOG guidelines
USP Class VI compliant and Animal Derived Component Free (ACDF)
Raw material assigned FDA drug master number: DMF 9040 and fulfils requirements of European pharmacopoeia, 5th edition (2004) and supplement 5.8 (07/2007), monograph 3.2.2.
年代uitable for sterilisation by autoclave and gamma irradiation
Lot traceability
Precision compression between tube and fittings eliminates flow bypass and media entrapment

Validation summary guide

The summary guide summarises the validation/qualification testing that has been carried out on BioPure components

View BioPure components summary guide - 379.5kb

Request full validation guide

First name*

Last name*

Email address*

Company*

Message

Disclaimer: You hereby agree the provided validation guide is for private use only to assist in the qualification of the products listed within the validation guide.

You also agree that you will not copy, redistribute, transmit, assign, sell, broadcast, rent, share, lend, modify, adapt, edit or transfer the validation guide to any other party without prior consent from WMFTS.

Yes

Literature

Brochures

BioPure overview (EN).pdf
PDF - 863.8kb
Bioprocessing (EN).pdf
PDF - 3.5mb

Datasheet

Other Resources

½ inch - ¾ inch Flat BioEndCap technical drawing.pdf
PDF - 1.5mb
1 inch - 1½ inch Flat BioEndCap technical drawing.pdf
PDF - 1.4mb
2 inch Flat BioEndCap technical drawing.pdf
PDF - 1.5mb
2½ inch Flat BioEndCap technical drawing.pdf
PDF - 1.5mb

Order Information

Product codes

FlatBioEndCap product codes

Part Number	年代ize	Flange Size	Material
PEC050075FC	1/2" - 3/4" TC	1/2" - 3/4"	Natural PP
PEC100150FC	1" - 1 1/2" TC	1" - 1 1/2"	Natural PP
PEC-200-FC	2" TC	2"	Natural PP
PEC-250-FC	2 1/2" TC	2 1/2"	Natural PP
